SOM2000D Operation Microscope
Description:
- Germany Schott optics ensure bright, balanced, and precise observation for the surgeon.
- Apochromatic technology in the optical design ensures coaxial light focus and provides a clearer field of view.
- Locking device under the microscope arm ensures safe distance and prevents accidents.
- Independent electrical control box with automatic diagnosis function, making installation and repairs convenient.
Objective Magnification
Five-step Drum Magnification
Eye Piece
12.5
Magnifications (Field of view)
6.3(33mm) 10(22.5mm) 16(14mm) 25(08.8mm) 40x(05.5mm)
Pupil Distance
55mm - 75mm
Diopter Adjustment
-5D- +3D
Slit Width
0mm - 14mm adjustable(slit is round when the slit width is 14mm)
Slit Height
1mm - 14mm adjustable
Diameter of Light Spot
14mm,p10mm,p5mm,p2mm,p1mm,0.2mm
Slit Angle
0° - 180° adjustable
Slit Inclination
5°, 10°, 15°, 20° four steps
Filers
Heat Absorption, Grey, Redfree, Cobalt blue
Illumination Source
12V30W halogen bulb
Collecting Medium
Digital Single Lens Reflex
Illumination Type of Taking Picture
Background Illumination
Power Supply
AC110V/220V±10%, 50Hz/60Hz
Optional Accessories
Applanation Tonometer,Measuring EyePiece,Trihedron Lens,Gonioscope,Funduscope,Aspheric Lens
Dynamic Display
LCD and Computer Screen Rael-time Dynamic Display
Packing Volume
670mmx620mmx490mm
Total Weight
23Kg(Table,Tabletop and Computer Not Included)
Processing Functions
Length ,Angle ,Area, Measuring ,Arrowhead, Word adding, Image processing
Power supply
AC110V/220V±10%，50Hz/60Hz
